Category |
Brand |
Model |
Accuracy |
Unit |
Height Gauge Measurements
|
OPTIHITE |
450 |
+/-0.005 |
1 |
Digital Height Gauge
|
MITUTOYO |
570 series |
+/-0.005 |
1 |
Digital Dial Indicator
|
MITUTOYO |
BD10-783 |
+/-0.005 |
2 |
INSIZE |
2103-10 |
+/-0.005 |
1 |
Digital Vernier Caliper
|
MITUTOYO |
500-196 |
+/-0.010 |
11 |
INSIZE |
1108-200 |
+/-0.010 |
7 |
Digital Micrometer
|
MITUTOYO |
293-240 |
+/-0.0010 |
7 |
INSIZE |
3108-25 |
+/-0.0010 |
4 |
Pin Gauge set
|
1mm~100mm |
|
+/-0.005 |
2 |
Slip Gauge set
|
0.5mm~100mm |
|
+/-0.005 |
1 |
Thread Gauge set
|
M2~M50 |
|
Go/No Go |
1 |
|
|
|
|
|
|
Profile Projector |
Manual Quick Vision |
Auto Quick Vision Active |
Auto Quick Vision Active |
|
|
|
|
Specification |
Modal |
Measuring Range (XxYxZ) |
250x200x150 |
Resolution |
0.1µm |
Scale Type |
Linear Encoder |
Observation Unit Type |
Zoom (8 positions) |
Image Sensor |
Color CMOS camera |
Illumination Unit |
Co-axial Light |
White LED |
Transmitted Light |
4-quadrant fixed white LED |
PRL |
(2+3L/1000)µm |
Accuracy |
E1X, E1Y |
(3+5L/1000)µm |
E1Z |
(2.5+4L/1000)µm |
E2 |
Z-objective 1.5X and 3.5X Zoom ratio |
Accuracy guaranteed with optics specified |
|
Size |
311X269mm |
Dimensions (WxDxH) |
570x767x845mm |
|
|
|
|
- CMM material No. 1 is used for the XOrbit Granite
- The base plate, the cross-beam and the quill are madefrom granite thus ensuring an identical thermal reaction in all axes
- High-tensile air bearing guide ways in the Y-axis with very precisely lapped locating surfaces incorporated in the granite base plate: A guarantee for outstanding long-term stability.
- Self-cleaning and wear-free air bearings in all axes ensure easy operation.
- Good accessibility during maintenance work.
|
|
|
|
